Waste radiator Recycling equipment

Due to the large production volume, variety, wide sources and difficulty in supervision, waste radiators are potentially a big environmental risk and must be properly disposed of or resourcefully utilized. Along with industrial development, the number of waste radiators discharged in the production process is increasing, and many small and medium-sized enterprises, there are generally less hazardous waste generation, transfer and disposal difficulties, not timely, etc. If improper disposal, it is easy to cause serious pollution to the ecological environment.

Copper and aluminum radiator recycling

The system of copper and aluminum separator for waste radiator is an intelligent, modular and one-stop radiator separation solution developed by SUNY GROUP for the characteristics of waste radiator treatment, taking advantage of its own technical advantages, integrating the increase system, storage bin, protection system, crushing system, fire fighting system, intelligent control system and maintenance system, which can provide customers with intelligent separation and sorting equipment.

Radiator copper and aluminum separation equipment crushing and sorting workflow:

Structural drawing of copper aluminum radiator

1、The waste radiator will be put into the coarse crusher, and the coarse crusher will crush the waste radiator, and the particle size of the coarse crushed material is less than or equal to 200mm;

2、After coarse crushing, the material particles fall into a conveying device and are transported forward by a conveying device to the inlet of the fine crusher;

3, by the fine crusher on the material particles for fine crushing, and, after the fine crushing of the material particles size less than or equal to 50mm;

4, after the fine crushing of the material particles fall into the second conveyor device, and by the second conveyor device forward transported to the sorting machine inlet, at the same time, set in the second conveyor device of the magnetic separator with magnetic suction will be the material particles in the iron particles adsorption recovery;

5, in the sorter, the specific gravity of copper particles from the sorter of the large specific gravity material outlet, the specific gravity of small aluminum particles from the sorter of the small specific gravity material outlet is adsorbed to a cyclone dust collector, and in a cyclone dust collector 7 of the dust discharge port separation out.

Product features:

1、The machine is suitable for the internal copper and aluminum of waste air conditioners, old radiators, end-of-life water tanks, disassembly and separation;

2、This machine can separate the internal copper and aluminum of waste radiator and so on quickly to keep the original state;

3、Adopt PLC automatic control, so that the system equipment between the coordinated work, reliable working environment;

4、The dismantling process of this machine is completed by one machine, no other equipment auxiliary production;

5, supporting the magnetic separation equipment, using strong magnetic drum type sorter, separating out the non-ferrous gold and iron metal contained in the material;

6, specific gravity sorting principle, using airflow sorting machine, the degree of separation up to 98%;
